Roland SonicCell User Manual

268
MIDI Implementation
| | | L64 - 63R |
| 00 05 | 000a aaaa | Tone Pan Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 06 | 00aa aaaa | Tone Random Pan Depth (0 - 63) |
| 00 07 | 0aaa aaaa | Tone Alternate Pan Depth (1 - 127) |
| | | L63 - 63R |
| 00 08 | 0000 000a | Tone Env Mode (0 - 1) |
| | | NO-SUS, SUSTAIN |
| 00 09 | 0000 00aa | Tone Delay Mode (0 - 3) |
| | | NORMAL, HOLD, KEY-OFF-NORMAL, |
| | | KEY-OFF-DECAY |
|# 00 0A | 0000 aaaa | |
| | 0000 bbbb | Tone Delay Time (0 - 149) |
| | | 0 - 127, MUSICAL-NOTES |
|-------------+-----------+----------------------------------------------------|
| 00 0C | 0aaa aaaa | Tone Dry Send Level (0 - 127) |
| 00 0D | 0aaa aaaa | Tone Chorus Send Level (MFX) (0 - 127) |
| 00 0E | 0aaa aaaa | Tone Reverb Send Level (MFX) (0 - 127) |
| 00 0F | 0aaa aaaa | Tone Chorus Send Level (non MFX) (0 - 127) |
| 00 10 | 0aaa aaaa | Tone Reverb Send Level (non MFX) (0 - 127) |
| 00 11 | 0000 aaaa | Tone Output Assign (0 - 12) |
| | | MFX, A, ---, ---, ---, |
| | | 1, 2, ---, ---, ---, ---, ---, --- |
|-------------+-----------+----------------------------------------------------|
| 00 12 | 0000 000a | Tone Receive Bender (0 - 1) |
| | | OFF, ON |
| 00 13 | 0000 000a | Tone Receive Expression (0 - 1) |
| | | OFF, ON |
| 00 14 | 0000 000a | Tone Receive Hold-1 (0 - 1) |
| | | OFF, ON |
| 00 15 | 0000 000a | Tone Receive Pan Mode (0 - 1) |
| | | CONTINUOUS, KEY-ON |
| 00 16 | 0000 000a | Tone Redamper Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 17 | 0000 00aa | Tone Control 1 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 18 | 0000 00aa | Tone Control 1 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 19 | 0000 00aa | Tone Control 1 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1A | 0000 00aa | Tone Control 1 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1B | 0000 00aa | Tone Control 2 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1C | 0000 00aa | Tone Control 2 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1D | 0000 00aa | Tone Control 2 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1E | 0000 00aa | Tone Control 2 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 1F | 0000 00aa | Tone Control 3 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 20 | 0000 00aa | Tone Control 3 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 21 | 0000 00aa | Tone Control 3 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 22 | 0000 00aa | Tone Control 3 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 23 | 0000 00aa | Tone Control 4 Switch 1 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 24 | 0000 00aa | Tone Control 4 Switch 2 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 25 | 0000 00aa | Tone Control 4 Switch 3 (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 26 | 0000 00aa | Tone Control 4 Switch 4 (0 - 2) |
| | | OFF, ON, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 27 | 0000 00aa | Wave Group Type (0 - 1) |
| | | INT, SRX |
|# 00 28 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Wave Group ID (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Wave Number L (Mono) (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 30 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Wave Number R (0 - 16384) |
| | | OFF, 1 - 16384 |
| 00 34 | 0000 00aa | Wave Gain (0 - 3) |
| | | -6, 0, +6, +12 [dB] |
| 00 35 | 0000 000a | Wave FXM Switch (0 - 1) |
| | | OFF, ON |
| 00 36 | 0000 00aa | Wave FXM Color (0 - 3) |
| | | 1 - 4 |
| 00 37 | 000a aaaa | Wave FXM Depth (0 - 16) |
| 00 38 | 0000 000a | Wave Tempo Sync (0 - 1) |
| | | OFF, ON |
| 00 39 | 00aa aaaa | Wave Pitch Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
| 00 3A | 000a aaaa | Pitch Env Depth (52 - 76) |
| | | -12 - +12 |
| 00 3B | 0aaa aaaa | Pitch Env Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3C | 0aaa aaaa | Pitch Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3D | 0aaa aaaa | Pitch Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 3E | 000a aaaa | Pitch Env Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 3F | 0aaa aaaa | Pitch Env Time 1 (0 - 127) |
| 00 40 | 0aaa aaaa | Pitch Env Time 2 (0 - 127) |
| 00 41 | 0aaa aaaa | Pitch Env Time 3 (0 - 127) |
| 00 42 | 0aaa aaaa | Pitch Env Time 4 (0 - 127) |
| 00 43 | 0aaa aaaa | Pitch Env Level 0 (1 - 127) |
| | | -63 - +63 |
| 00 44 | 0aaa aaaa | Pitch Env Level 1 (1 - 127) |
| | | -63 - +63 |
| 00 45 | 0aaa aaaa | Pitch Env Level 2 (1 - 127) |
| | | -63 - +63 |
| 00 46 | 0aaa aaaa | Pitch Env Level 3 (1 - 127) |
| | | -63 - +63 |
| 00 47 | 0aaa aaaa | Pitch Env Level 4 (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 48 | 0000 0aaa | TVF Filter Type (0 - 6) |
| | | OFF, LPF, BPF, HPF, PKG, LPF2, |
| | | LPF3 |
| 00 49 | 0aaa aaaa | TVF Cutoff Frequency (0 - 127) |
| 00 4A | 00aa aaaa | TVF Cutoff Keyfollow (44 - 84) |
| | | -200 - +200 |
| 00 4B | 0000 0aaa | TVF Cutoff Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 4C | 0aaa aaaa | TVF Cutoff Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4D | 0aaa aaaa | TVF Resonance (0 - 127) |
| 00 4E | 0aaa aaaa | TVF Resonance Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 4F | 0aaa aaaa | TVF Env Depth (1 - 127) |
| | | -63 - +63 |
| 00 50 | 0000 0aaa | TVF Env Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 51 | 0aaa aaaa | TVF Env Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 52 | 0aaa aaaa | TVF Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 53 | 0aaa aaaa | TVF Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 54 | 000a aaaa | TVF Env Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 55 | 0aaa aaaa | TVF Env Time 1 (0 - 127) |
| 00 56 | 0aaa aaaa | TVF Env Time 2 (0 - 127) |
| 00 57 | 0aaa aaaa | TVF Env Time 3 (0 - 127) |
| 00 58 | 0aaa aaaa | TVF Env Time 4 (0 - 127) |
| 00 59 | 0aaa aaaa | TVF Env Level 0 (0 - 127) |
| 00 5A | 0aaa aaaa | TVF Env Level 1 (0 - 127) |
| 00 5B | 0aaa aaaa | TVF Env Level 2 (0 - 127) |
| 00 5C | 0aaa aaaa | TVF Env Level 3 (0 - 127) |
| 00 5D | 0aaa aaaa | TVF Env Level 4 (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 5E | 000a aaaa | Bias Level (54 - 74) |
| | | -100 - +100 |
| 00 5F | 0aaa aaaa | Bias Position (0 - 127) |
| | | C-1 - G9 |
| 00 60 | 0000 00aa | Bias Direction (0 - 3) |
| | | LOWER, UPPER, LOWER&UPPER, ALL |
| 00 61 | 0000 0aaa | TVA Level Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 62 | 0aaa aaaa | TVA Level Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 63 | 0aaa aaaa | TVA Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 64 | 0aaa aaaa | TVA Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 65 | 000a aaaa | TVA Env Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 66 | 0aaa aaaa | TVA Env Time 1 (0 - 127) |
| 00 67 | 0aaa aaaa | TVA Env Time 2 (0 - 127) |
| 00 68 | 0aaa aaaa | TVA Env Time 3 (0 - 127) |
| 00 69 | 0aaa aaaa | TVA Env Time 4 (0 - 127) |
| 00 6A | 0aaa aaaa | TVA Env Level 1 (0 - 127) |
| 00 6B | 0aaa aaaa | TVA Env Level 2 (0 - 127) |
| 00 6C | 0aaa aaaa | TVA Env Level 3 (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 6D | 0000 aaaa | LFO1 Waveform (0 - 12) |
| | | SIN, TRI, SAW-UP, SAW-DW, SQR, |
| | | RND, BEND-UP, BEND-DW, TRP, S&H, |
| | | CHS, VSIN, STEP |
|# 00 6E | 0000 aaaa | |
| | 0000 bbbb | LFO1 Rate (0 - 149) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 70 | 0000 0aaa | LFO1 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 71 | 0aaa aaaa | LFO1 Rate Detune (0 - 127) |
| 00 72 | 0aaa aaaa | LFO1 Delay Time (0 - 127) |
| 00 73 | 000a aaaa | LFO1 Delay Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 00 74 | 0000 00aa | LFO1 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 75 | 0aaa aaaa | LFO1 Fade Time (0 - 127) |
| 00 76 | 0000 000a | LFO1 Key Trigger (0 - 1) |
