269
MIDI Implementation
| | | OFF, ON |
| 00 77 | 0aaa aaaa | LFO1 Pitch Depth (1 - 127) |
| | | -63 - +63 |
| 00 78 | 0aaa aaaa | LFO1 TVF Depth (1 - 127) |
| | | -63 - +63 |
| 00 79 | 0aaa aaaa | LFO1 TVA Depth (1 - 127) |
| | | -63 - +63 |
| 00 7A | 0aaa aaaa | LFO1 Pan Depth (1 - 127) |
| | | -63 - +63 |
| 00 7B | 0000 aaaa | LFO2 Waveform (0 - 12) |
| | | SIN, TRI, SAW-UP, SAW-DW, SQR, |
| | | RND, BEND-UP, BEND-DW, TRP, S&H, |
| | | CHS, VSIN, STEP |
|# 00 7C | 0000 aaaa | |
| | 0000 bbbb | LFO2 Rate (0 - 149) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 7E | 0000 0aaa | LFO2 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 7F | 0aaa aaaa | LFO2 Rate Detune (0 - 127) |
| 01 00 | 0aaa aaaa | LFO2 Delay Time (0 - 127) |
| 01 01 | 000a aaaa | LFO2 Delay Time Keyfollow (54 - 74) |
| | | -100 - +100 |
| 01 02 | 0000 00aa | LFO2 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 01 03 | 0aaa aaaa | LFO2 Fade Time (0 - 127) |
| 01 04 | 0000 000a | LFO2 Key Trigger (0 - 1) |
| | | OFF, ON |
| 01 05 | 0aaa aaaa | LFO2 Pitch Depth (1 - 127) |
| | | -63 - +63 |
| 01 06 | 0aaa aaaa | LFO2 TVF Depth (1 - 127) |
| | | -63 - +63 |
| 01 07 | 0aaa aaaa | LFO2 TVA Depth (1 - 127) |
| | | -63 - +63 |
| 01 08 | 0aaa aaaa | LFO2 Pan Depth (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 01 09 | 0000 aaaa | LFO Step Type (0 - 1) |
| 01 0A | 0aaa aaaa | LFO Step1 (28 - 100) |
| | | -36 - +36 |
| 01 0B | 0aaa aaaa | LFO Step2 (28 - 100) |
| | | -36 - +36 |
| 01 0C | 0aaa aaaa | LFO Step3 (28 - 100) |
| | | -36 - +36 |
| 01 0D | 0aaa aaaa | LFO Step4 (28 - 100) |
| | | -36 - +36 |
| 01 0E | 0aaa aaaa | LFO Step5 (28 - 100) |
| | | -36 - +36 |
| 01 0F | 0aaa aaaa | LFO Step6 (28 - 100) |
| | | -36 - +36 |
| 01 10 | 0aaa aaaa | LFO Step7 (28 - 100) |
| | | -36 - +36 |
| 01 11 | 0aaa aaaa | LFO Step8 (28 - 100) |
| | | -36 - +36 |
| 01 12 | 0aaa aaaa | LFO Step9 (28 - 100) |
| | | -36 - +36 |
| 01 13 | 0aaa aaaa | LFO Step10 (28 - 100) |
| | | -36 - +36 |
| 01 14 | 0aaa aaaa | LFO Step11 (28 - 100) |
| | | -36 - +36 |
| 01 15 | 0aaa aaaa | LFO Step12 (28 - 100) |
| | | -36 - +36 |
| 01 16 | 0aaa aaaa | LFO Step13 (28 - 100) |
| | | -36 - +36 |
| 01 17 | 0aaa aaaa | LFO Step14 (28 - 100) |
| | | -36 - +36 |
| 01 18 | 0aaa aaaa | LFO Step15 (28 - 100) |
| | | -36 - +36 |
| 01 19 | 0aaa aaaa | LFO Step16 (28 - 100) |
| | | -36 - +36 |
|-------------+----------------------------------------------------------------|
| 00 00 01 1A | Total Size |
+------------------------------------------------------------------------------+
* Rhythm Common
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | Rhythm Name 1 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 01 | 0aaa aaaa | Rhythm Name 2 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 02 | 0aaa aaaa | Rhythm Name 3 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 03 | 0aaa aaaa | Rhythm Name 4 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 04 | 0aaa aaaa | Rhythm Name 5 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 05 | 0aaa aaaa | Rhythm Name 6 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 06 | 0aaa aaaa | Rhythm Name 7 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 07 | 0aaa aaaa | Rhythm Name 8 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 08 | 0aaa aaaa | Rhythm Name 9 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 09 | 0aaa aaaa | Rhythm Name 10 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0A | 0aaa aaaa | Rhythm Name 11 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0B | 0aaa aaaa | Rhythm Name 12 (32 - 127) |
| | | 32 - 127 [ASCII] |
|-------------+-----------+----------------------------------------------------|
| 00 0C | 0aaa aaaa | Rhythm Level (0 - 127) |
| 00 0D | 0000 000a | (reserve) |
|# 00 0E | 0000 aaaa | |
| | 0000 bbbb | (reserve) |
| 00 10 | 0000 000a | (reserve) |
|-------------+-----------+----------------------------------------------------|
| 00 11 | 0000 aaaa | Rhythm Output Assign (0 - 13) |
| | | MFX, A, ---, ---, ---, |
| | | 1, 2, ---, ---, ---, ---, ---, ---, |
| | | TONE |
|-------------+----------------------------------------------------------------|
| 00 00 00 12 | Total Size |
+------------------------------------------------------------------------------+
* Rhythm Common MFX
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | MFX Type (0 - 78) |
| 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) |
| 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) |
| 00 04 | 0000 00aa | MFX Output Assign <*> |
| | | A, ---, ---, --- |
|-------------+-----------+----------------------------------------------------|
| 00 05 | 0aaa aaaa | MFX Control 1 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 06 | 0aaa aaaa | MFX Control 1 Sens (1 - 127) |
| | | -63 - +63 |
| 00 07 | 0aaa aaaa | MFX Control 2 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 08 | 0aaa aaaa | MFX Control 2 Sens (1 - 127) |
| | | -63 - +63 |
| 00 09 | 0aaa aaaa | MFX Control 3 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 0A | 0aaa aaaa | MFX Control 3 Sens (1 - 127) |
| | | -63 - +63 |
| 00 0B | 0aaa aaaa | MFX Control 4 Source (0 - 101) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND, AFT, SYS1 - SYS4 |
| 00 0C | 0aaa aaaa | MFX Control 4 Sens (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) |
| | | OFF, 1 - 16 |
| 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) |
| | | OFF, 1 - 16 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 21 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 25 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 29 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2D | 0000 aaaa | |
SonicCell_e.book 269 ページ ２００７年８月９日　木曜日　午後９時１７分
