Roland SonicCell User Manual

272
MIDI Implementation
| 00 0D | 000a aaaa | Mute Group (0 - 31) |
| | | OFF, 1 - 31 |
|-------------+-----------+----------------------------------------------------|
| 00 0E | 0aaa aaaa | Tone Level (0 - 127) |
| 00 0F | 0aaa aaaa | Tone Coarse Tune (0 - 127) |
| | | C-1 - G9 |
| 00 10 | 0aaa aaaa | Tone Fine Tune (14 - 114) |
| | | -50 - +50 |
| 00 11 | 000a aaaa | Tone Random Pitch Depth (0 - 30) |
| | | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
| | | 10, 20, 30, 40, 50, 60, 70, 80, |
| | | 90, 100, 200, 300, 400, 500, |
| | | 600, 700, 800, 900, 1000, 1100, |
| | | 1200 |
| 00 12 | 0aaa aaaa | Tone Pan (0 - 127) |
| | | L64 - 63R |
| 00 13 | 00aa aaaa | Tone Random Pan Depth (0 - 63) |
| 00 14 | 0aaa aaaa | Tone Alternate Pan Depth (1 - 127) |
| | | L63 - 63R |
| 00 15 | 0000 000a | Tone Env Mode (0 - 1) |
| | | NO-SUS, SUSTAIN |
|-------------+-----------+----------------------------------------------------|
| 00 16 | 0aaa aaaa | Tone Dry Send Level (0 - 127) |
| 00 17 | 0aaa aaaa | Tone Chorus Send Level (0 - 127) |
| 00 18 | 0aaa aaaa | Tone Reverb Send Level (0 - 127) |
| 00 19 | 0aaa aaaa | Tone Chorus Send Level (non MFX) (0 - 127) |
| 00 1A | 0aaa aaaa | Tone Reverb Send Level (non MFX) (0 - 127) |
| 00 1B | 0000 aaaa | Tone Output Assign (0 - 12) |
| | | MFX, A, ---, ---, ---, |
| | | 1, 2, ---, ---, ---, ---, ---, --- |
|-------------+-----------+----------------------------------------------------|
| 00 1C | 00aa aaaa | Tone Pitch Bend Range (0 - 48) |
| 00 1D | 0000 000a | Tone Receive Expression (0 - 1) |
| | | OFF, ON |
| 00 1E | 0000 000a | Tone Receive Hold-1 (0 - 1) |
| | | OFF, ON |
| 00 1F | 0000 000a | Tone Receive Pan Mode (0 - 1) |
| | | CONTINUOUS, KEY-ON |
|-------------+-----------+----------------------------------------------------|
| 00 20 | 0000 00aa | WMT Velocity Control (0 - 2) |
| | | OFF, ON, RANDOM |
|-------------+-----------+----------------------------------------------------|
| 00 21 | 0000 000a | WMT1 Wave Switch (0 - 1) |
| | | OFF, ON |
| 00 22 | 0000 00aa | WMT1 Wave Group Type (0 - 1) |
| | | INT, SRX |
|# 00 23 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT1 Wave Group ID (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 27 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT1 Wave Number L (Mono) (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 2B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT1 Wave Number R (0 - 16384) |
| | | OFF, 1 - 16384 |
| 00 2F | 0000 00aa | WMT1 Wave Gain (0 - 3) |
| | | -6, 0, +6, +12 [dB] |
| 00 30 | 0000 000a | WMT1 Wave FXM Switch (0 - 1) |
| | | OFF, ON |
| 00 31 | 0000 00aa | WMT1 Wave FXM Color (0 - 3) |
| | | 1 - 4 |
| 00 32 | 000a aaaa | WMT1 Wave FXM Depth (0 - 16) |
| 00 33 | 0000 000a | WMT1 Wave Tempo Sync (0 - 1) |
| | | OFF, ON |
| 00 34 | 0aaa aaaa | WMT1 Wave Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 00 35 | 0aaa aaaa | WMT1 Wave Fine Tune (14 - 114) |
| | | -50 - +50 |
| 00 36 | 0aaa aaaa | WMT1 Wave Pan (0 - 127) |
| | | L64 - 63R |
| 00 37 | 0000 000a | WMT1 Wave Random Pan Switch (0 - 1) |
| | | OFF, ON |
| 00 38 | 0000 00aa | WMT1 Wave Alternate Pan Switch (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 39 | 0aaa aaaa | WMT1 Wave Level (0 - 127) |
| 00 3A | 0aaa aaaa | WMT1 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 3B | 0aaa aaaa | WMT1 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 3C | 0aaa aaaa | WMT1 Velocity Fade Width Lower (0 - 127) |
| 00 3D | 0aaa aaaa | WMT1 Velocity Fade Width Upper (0 - 127) |
| 00 3E | 0000 000a | WMT2 Wave Switch (0 - 1) |
| | | OFF, ON |
| 00 3F | 0000 00aa | WMT2 Wave Group Type (0 - 1) |
| | | INT, SRX |
|# 00 40 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT2 Wave Group ID (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 44 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT2 Wave Number L (Mono) (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 48 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT2 Wave Number R (0 - 16384) |
| | | OFF, 1 - 16384 |
| 00 4C | 0000 00aa | WMT2 Wave Gain (0 - 3) |
| | | -6, 0, +6, +12 [dB] |
| 00 4D | 0000 000a | WMT2 Wave FXM Switch (0 - 1) |
| | | OFF, ON |
| 00 4E | 0000 00aa | WMT2 Wave FXM Color (0 - 3) |
| | | 1 - 4 |
| 00 4F | 000a aaaa | WMT2 Wave FXM Depth (0 - 16) |
| 00 50 | 0000 000a | WMT2 Wave Tempo Sync (0 - 1) |
| | | OFF, ON |
| 00 51 | 0aaa aaaa | WMT2 Wave Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 00 52 | 0aaa aaaa | WMT2 Wave Fine Tune (14 - 114) |
| | | -50 - +50 |
| 00 53 | 0aaa aaaa | WMT2 Wave Pan (0 - 127) |
| | | L64 - 63R |
| 00 54 | 0000 000a | WMT2 Wave Random Pan Switch (0 - 1) |
| | | OFF, ON |
| 00 55 | 0000 00aa | WMT2 Wave Alternate Pan Switch (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 56 | 0aaa aaaa | WMT2 Wave Level (0 - 127) |
| 00 57 | 0aaa aaaa | WMT2 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 58 | 0aaa aaaa | WMT2 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 59 | 0aaa aaaa | WMT2 Velocity Fade Width Lower (0 - 127) |
| 00 5A | 0aaa aaaa | WMT2 Velocity Fade Width Upper (0 - 127) |
| 00 5B | 0000 000a | WMT3 Wave Switch (0 - 1) |
| | | OFF, ON |
| 00 5C | 0000 00aa | WMT3 Wave Group Type (0 - 1) |
| | | INT, SRX |
|# 00 5D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT3 Wave Group ID (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 61 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT3 Wave Number L (Mono) (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 65 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT3 Wave Number R (0 - 16384) |
| | | OFF, 1 - 16384 |
| 00 69 | 0000 00aa | WMT3 Wave Gain (0 - 3) |
| | | -6, 0, +6, +12 [dB] |
| 00 6A | 0000 000a | WMT3 Wave FXM Switch (0 - 1) |
| | | OFF, ON |
| 00 6B | 0000 00aa | WMT3 Wave FXM Color (0 - 3) |
| | | 1 - 4 |
| 00 6C | 000a aaaa | WMT3 Wave FXM Depth (0 - 16) |
| 00 6D | 0000 000a | WMT3 Wave Tempo Sync (0 - 1) |
| | | OFF, ON |
| 00 6E | 0aaa aaaa | WMT3 Wave Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 00 6F | 0aaa aaaa | WMT3 Wave Fine Tune (14 - 114) |
| | | -50 - +50 |
| 00 70 | 0aaa aaaa | WMT3 Wave Pan (0 - 127) |
| | | L64 - 63R |
| 00 71 | 0000 000a | WMT3 Wave Random Pan Switch (0 - 1) |
| | | OFF, ON |
| 00 72 | 0000 00aa | WMT3 Wave Alternate Pan Switch (0 - 2) |
| | | OFF, ON, REVERSE |
| 00 73 | 0aaa aaaa | WMT3 Wave Level (0 - 127) |
| 00 74 | 0aaa aaaa | WMT3 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 00 75 | 0aaa aaaa | WMT3 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 00 76 | 0aaa aaaa | WMT3 Velocity Fade Width Lower (0 - 127) |
| 00 77 | 0aaa aaaa | WMT3 Velocity Fade Width Upper (0 - 127) |
| 00 78 | 0000 000a | WMT4 Wave Switch (0 - 1) |
| | | OFF, ON |
| 00 79 | 0000 00aa | WMT4 Wave Group Type (0 - 1) |
| | | INT, SRX |
|# 00 7A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT4 Wave Group ID (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 00 7E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT4 Wave Number L (Mono) (0 - 16384) |
| | | OFF, 1 - 16384 |
|# 01 02 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | WMT4 Wave Number R (0 - 16384) |
| | | OFF, 1 - 16384 |
| 01 06 | 0000 00aa | WMT4 Wave Gain (0 - 3) |
| | | -6, 0, +6, +12 [dB] |
SonicCell_e.book 272 ページ ２００７年８月９日 木曜日 午後９時１７分
