Roland SonicCell User Manual

273
MIDI Implementation
| 01 07 | 0000 000a | WMT4 Wave FXM Switch (0 - 1) |
| | | OFF, ON |
| 01 08 | 0000 00aa | WMT4 Wave FXM Color (0 - 3) |
| | | 1 - 4 |
| 01 09 | 000a aaaa | WMT4 Wave FXM Depth (0 - 16) |
| 01 0A | 0000 000a | WMT4 Wave Tempo Sync (0 - 1) |
| | | OFF, ON |
| 01 0B | 0aaa aaaa | WMT4 Wave Coarse Tune (16 - 112) |
| | | -48 - +48 |
| 01 0C | 0aaa aaaa | WMT4 Wave Fine Tune (14 - 114) |
| | | -50 - +50 |
| 01 0D | 0aaa aaaa | WMT4 Wave Pan (0 - 127) |
| | | L64 - 63R |
| 01 0E | 0000 000a | WMT4 Wave Random Pan Switch (0 - 1) |
| | | OFF, ON |
| 01 0F | 0000 00aa | WMT4 Wave Alternate Pan Switch (0 - 2) |
| | | OFF, ON, REVERSE |
| 01 10 | 0aaa aaaa | WMT4 Wave Level (0 - 127) |
| 01 11 | 0aaa aaaa | WMT4 Velocity Range Lower (1 - 127) |
| | | 1 - UPPER |
| 01 12 | 0aaa aaaa | WMT4 Velocity Range Upper (1 - 127) |
| | | LOWER - 127 |
| 01 13 | 0aaa aaaa | WMT4 Velocity Fade Width Lower (0 - 127) |
| 01 14 | 0aaa aaaa | WMT4 Velocity Fade Width Upper (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 01 15 | 000a aaaa | Pitch Env Depth (52 - 76) |
| | | -12 - +12 |
| 01 16 | 0aaa aaaa | Pitch Env Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 17 | 0aaa aaaa | Pitch Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 18 | 0aaa aaaa | Pitch Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 19 | 0aaa aaaa | Pitch Env Time 1 (0 - 127) |
| 01 1A | 0aaa aaaa | Pitch Env Time 2 (0 - 127) |
| 01 1B | 0aaa aaaa | Pitch Env Time 3 (0 - 127) |
| 01 1C | 0aaa aaaa | Pitch Env Time 4 (0 - 127) |
| 01 1D | 0aaa aaaa | Pitch Env Level 0 (1 - 127) |
| | | -63 - +63 |
| 01 1E | 0aaa aaaa | Pitch Env Level 1 (1 - 127) |
| | | -63 - +63 |
| 01 1F | 0aaa aaaa | Pitch Env Level 2 (1 - 127) |
| | | -63 - +63 |
| 01 20 | 0aaa aaaa | Pitch Env Level 3 (1 - 127) |
| | | -63 - +63 |
| 01 21 | 0aaa aaaa | Pitch Env Level 4 (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 01 22 | 0000 0aaa | TVF Filter Type (0 - 6) |
| | | OFF, LPF, BPF, HPF, PKG, LPF2, |
| | | LPF3 |
| 01 23 | 0aaa aaaa | TVF Cutoff Frequency (0 - 127) |
| 01 24 | 0000 0aaa | TVF Cutoff Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 25 | 0aaa aaaa | TVF Cutoff Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 26 | 0aaa aaaa | TVF Resonance (0 - 127) |
| 01 27 | 0aaa aaaa | TVF Resonance Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 28 | 0aaa aaaa | TVF Env Depth (1 - 127) |
| | | -63 - +63 |
| 01 29 | 0000 0aaa | TVF Env Velocity Curve Type (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 2A | 0aaa aaaa | TVF Env Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 2B | 0aaa aaaa | TVF Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 2C | 0aaa aaaa | TVF Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 2D | 0aaa aaaa | TVF Env Time 1 (0 - 127) |
| 01 2E | 0aaa aaaa | TVF Env Time 2 (0 - 127) |
| 01 2F | 0aaa aaaa | TVF Env Time 3 (0 - 127) |
| 01 30 | 0aaa aaaa | TVF Env Time 4 (0 - 127) |
| 01 31 | 0aaa aaaa | TVF Env Level 0 (0 - 127) |
| 01 32 | 0aaa aaaa | TVF Env Level 1 (0 - 127) |
| 01 33 | 0aaa aaaa | TVF Env Level 2 (0 - 127) |
| 01 34 | 0aaa aaaa | TVF Env Level 3 (0 - 127) |
| 01 35 | 0aaa aaaa | TVF Env Level 4 (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 01 36 | 0000 0aaa | TVA Level Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 37 | 0aaa aaaa | TVA Level Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 38 | 0aaa aaaa | TVA Env Time 1 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 39 | 0aaa aaaa | TVA Env Time 4 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 3A | 0aaa aaaa | TVA Env Time 1 (0 - 127) |
| 01 3B | 0aaa aaaa | TVA Env Time 2 (0 - 127) |
| 01 3C | 0aaa aaaa | TVA Env Time 3 (0 - 127) |
| 01 3D | 0aaa aaaa | TVA Env Time 4 (0 - 127) |
| 01 3E | 0aaa aaaa | TVA Env Level 1 (0 - 127) |
| 01 3F | 0aaa aaaa | TVA Env Level 2 (0 - 127) |
| 01 40 | 0aaa aaaa | TVA Env Level 3 (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 01 41 | 0000 000a | One Shot Mode (0 - 1) |
| | | OFF, ON |
| 01 42 | 0aaa aaaa | Relative Level (0 - 127) |
| | | -64 - +63 |
|-------------+----------------------------------------------------------------|
| 00 00 01 43 | Total Size |
+------------------------------------------------------------------------------+
2. GS (Model ID = 42H)
* System Parameter
+------------------------------------------------------------------------------+
| Start | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 40 00 7F | 0aaa aaaa | Mode Set (0, 127) |
| | | GS-RESET, GS-EXIT |
+------------------------------------------------------------------------------+
* Part Parameter
+------------------------------------------------------------------------------+
| Start | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 40 1x 40 | 0aaa aaaa | Scale Tuning C (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 41 | 0aaa aaaa | Scale Tuning C# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 42 | 0aaa aaaa | Scale Tuning D (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 43 | 0aaa aaaa | Scale Tuning D# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 44 | 0aaa aaaa | Scale Tuning E (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 45 | 0aaa aaaa | Scale Tuning F (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 46 | 0aaa aaaa | Scale Tuning F# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 47 | 0aaa aaaa | Scale Tuning G (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 48 | 0aaa aaaa | Scale Tuning G# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 49 | 0aaa aaaa | Scale Tuning A (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 4A | 0aaa aaaa | Scale Tuning A# (0 - 127) |
| | | -64 - +63 [cent] |
| 40 1x 4B | 0aaa aaaa | Scale Tuning B (0 - 127) |
| | | -64 - +63 [cent] |
+------------------------------------------------------------------------------+
x: BLOCK NUMBER (0-F)
Part 1 (MIDI ch = 1) x = 1
Part 2 (MIDI ch = 2) x = 2
: : :
Part 9 (MIDI ch = 9) x = 9
Part10 (MIDI ch = 10) x = 0
Part11 (MIDI ch = 11) x = A
Part12 (MIDI ch = 12) x = B
: : :
Part16 (MIDI ch = 16) x = F
