SCM CU 300C - Page 46

3 - TECHNICAL SPECIFICATIONS
EN
Pag. 4/22 - Cap. 3 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
SURFACE PLANING MACHINE
Max. thickness under the
guard
75 mm
Max. length
DANGER-WARNING: may be not defined; we recommend
to use table extensions (not supplied by SCM) at entry
and exit side in case of panels longer than 2000 mm.
300 mm
CU 300C
Max. width
410 mm
CU 410C
H
1
=30 mm
H
2
=20 mm
Min. thickness
H
3
=80 mm
We recommend to use pushers (not supplied by SCM).
Min. length 150 mm
DANGER-WARNING: never machine shorter workpieces.
S
1
=10 mm We recommend to use pushers (not supplied by SCM).
S
2
=15 mm
Min. width
S
3
=15 mm
DANGER-WARNING: never machine shorter workpieces.
