79 C32 conversion
If the C32 conversion parameter is activated, decoding is enabled for the relevant code
type.
NOTE
As only activated code types are processed, the processing speed can be increased by
specifically activating/deactivating the necessary code types.
•
Code name: C32 conversion (two-value)
•
Character set: 32 alphanumeric characters (upper-case letters A to Z, digits 0 to 9,
no special characters)
•
Structure: Leading quiet zone, start character, useful character, check character,
stop character, trailing quiet zone (13 to 16 modules per character)
•
Intrinsic safety: High
•
Spatial requirements: Variable symbol length
•
Standard: ISO/IEC 16388, ANSI/AIM BC5 1995
•
Areas of application: Part numbers for pharmaceutical products (Italian Pharma‐
code), packaging for human medicines
80
CAN
The CAN interface is configured on the CAN tab.
81 CAN Open Heartbeat Time / ms
The see "CAN Open Heartbeat Time / ms", page 38 parameter defines the time interval
between the CANopen heartbeat objects in ms.
The heartbeat protocol is used on CANopen networks to check the CAN nodes. The
CANopen heartbeat protocol stipulates that every CAN node must send out heartbeat
objects at cyclical intervals and receive them from other bus participants. The transmis‐
sion cycle must be configured.
SOPAS PARAMETER OVERVIEW
38
O N L I N E H E L P | Lector62x 8013778/YPV6/2016-01-14 | SICK
Subject to change without notice
