5 2D Components
If the GS1 DataBar parameter is activated, decoding is activated for the DataBar 14,
DataBar Expanded, and DataBar Limited activated code types. (This requires the GS1
DataBar code type to be deactivated.)
NOTE
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
6 2D Increase Performance
It is possible to optimize the decoding process for 2D codes via the parameters in the
2D Increase Performance group. The parameters can be used to eliminate interference,
thereby increasing device performance.
Adapting the settings to suit the application reduces the decoding time and increases
both reading reliability and the readability of low-contrast, 2D codes.
7 Add-on
The Add-on parameter allows you to adjust how the extended code structure is handled
(additional information generally found on magazines).
•
NONE: There is no extended code structure available within the code.
•
ACTIVE: There is an extended code structure available within the code.
•
REQUIRED: Only codes with an extended code structure are read.
8 Add-on length
The Add-on length parameter is used to define the length of the extended code struc‐
ture.
•
2 CHARACTERS: A 1
•
5 CHARACTERS: A 1 B 2 C
•
2 OR 5 CHARACTERS: A 1 or A 1 B 2 C
9 Address
The address of the image server to which the images for the SICK Visualization Platform
are to be sent is specified under the Address parameter.
10 Addressing mode
The Addressing mode parameter is used to specify whether the IP address of the sen‐
sor should be defined manually (STATICALLY) or assigned by a server (DHCP).
SOPAS PARAMETER OVERVIEW
14
