or
The or parameter can be used to select a second condition for deactivating the digital
output.
In order for the digital output to be deactivated, one of the conditions must be met.
•
---: No second condition selected
•
MATCH 1 CONDITION: The output is deactivated if the code that has been read corre‐
sponds to the MATCH 1 CONDITION match code.
•
MULTICODES1 CONDITION: The output is deactivated if the number of codes that have
been read corresponds to the number specified by the MULTICODES1 CONDITION.
•
TEACH-IN1 CONDITION: The output is deactivated if the code that has been read corre‐
sponds to the TEACH-IN1 CONDITION match code.
•
TEACH-IN2 CONDITION: The output is deactivated if the code that has been read corre‐
sponds to the TEACH-IN2 CONDITION match code.
Logic
The Logik parameter is used to select the polarity of the digital output.
•
NOT INVERTED: If this option is activated, the digital output switches from Low (0) to
High (1).
•
INVERTED: If this option is activated, the digital output switches from High (1) to Low
(0).
Control system
The Control system parameter allows you to choose between a configuration based on
length units and a configuration based on time units.
•
DISTANCE-CONTROLLED: The values for the Länge parameter are entered in mm.
•
TIME-CONTROLLED: The values for the Länge parameter are entered in ms.
Length
If the Inactive parameter is set to the TIMER/TRACKING condition, the Length parameter
can be used to specify how long the digital output should remain activated. The unit
can be selected via the Control system parameter.
42 Output / Result 3
The Output / Result 3 group contains the parameters for adjusting digital output 3.
NOTE
Digital outputs 3 and 4 are not available via the 15-pin D-Sub port on the CDB620 or
CDM420 connection module. They can only be utilized if a 17-pin open-ended cable is
used.
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
23
Subject to change without notice
