259 MicroSD card
If the MicroSD card parameter is activated, the captured images are stored perma‐
nently on the sensor's memory card.
This is only possible if a suitable memory card (MicroSD up to 32 GB, FAT file system)
has been inserted in the sensor.
Memory cards provide an easy way of expanding the available storage space. The
stored image files can be analyzed or undergo further processing on any PC.
NOTE
Many MicroSD cards restrict the number of files per folder to a maximum of 10,000.
Counter
The Counter parameter is used to define the numbering for the stored images.
•
CYCLIC NO.: The stored images are numbered consecutively up to a definable value
(Modulo). As soon as this value is reached, the numbering recommences at 1,
which results in existing images being overwritten. Likewise, when the device is
restarted or the configuration is changed, the numbering starts again from 1.
Cyclic numbering stores the images that were captured last.
•
TRIGGER NO.: The stored images are numbered consecutively. The number is
increased by 1 as soon as the reading gate opens. When the device is restarted,
the numbering starts again from 1. Once the memory is full, no more images can
be stored. Trigger-based numbering stores the images that were captured first.
Modulo
The Modulo parameter defines the maximum value for the counter.
As soon as this value is reached, the numbering recommences at 1, which results in
existing images being overwritten. In this way, you can restrict the maximum amount of
memory required by the stored images.
260 Check min. number of valid codes
If the Check min. number of valid codes parameter is activated, the system calculates
how many different codes there are and compares this number with a specified mini‐
mum (Minimum).
This can be used, for example, to check whether all the required codes are present on
an object.
261 Minimum bar width
The smallest structure for decoding a code is defined in mm via the Minimum bar width
parameter.
To optimize the decoding process, the value should be matched as precisely as possi‐
ble to the smallest code element (module width) that actually exists within the code. An
average module width must be specified so that codes with varying module widths can
still be read reliably.
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
91
Subject to change without notice
