you want to read a different code and then restore the settings more or less
straight away by performing a restart.
When menu mode is activated, the following functions can be accessed via the push‐
buttons on the sensor:
•
READ DIAGN: A suitable code is read in the reading area using the current configura‐
tion. The read rate for the last ten read operations is displayed in % above the bar
display on the sensor housing.
•
TEACH-IN MATCH CODE: A suitable code is read in the reading area and stored as a
match code (set code).
•
AUTO-SETUP (only available for DATA MATRIX for the time being): Depending on how the
parameters in the Auto-Setup via function button menu group are configured, the
reading distance, the image settings (brightness and contrast), and the code set‐
tings are adjusted automatically. In order for this to happen, a suitable object with
contrast variations or edges (e.g., code, text, or other structures) must be placed in
the reading area.
•
AUTOFOCUS: The focus position (reading distance) is adjusted automatically. In order
for this to happen, a suitable object with contrast variations or edges (e.g., code,
text, or other structures) must be placed in the reading area.
•
USERDEFINED: (not yet implemented)
185 Function buttons
The Function buttons group contains the parameters for defining the functions of the
sensor pushbuttons.
186 Gamma
The device's Gamma angle in relation to the trigger position is defined under the
Gamma parameter.
187 Device ID
The Device ID parameter assigns the device a unique number on the network. The
assigned ID is used as a CAN node for the CAN bus.
NOTE
If the device is connected to a SICK network via CAN, device IDs 1 to 63 can be
assigned. If the device is connected to a CANopen fieldbus, device IDs 1 to 127 can be
assigned. Duplicate IDs must not be assigned.
The device must be uniquely identified on the network to enable communication via
CAN bus and so that reading results can be correctly attributed to devices.
188
Device Information
The parameters in the Device Information group display sensor identification data.
This data is important in the context of servicing.
Manufacturer
The Manufacturer display field shows the sensor manufacturer.
Device type
The Gerätetyp display field shows the sensor device type.
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
71
Subject to change without notice
