135 Dot size
The Dot size parameter expands the code elements optically so that the sensor can be
adjusted to cope with poorly legible codes (e.g., codes with gaps between the dots of
the L-pattern).
: Poorly legible
: Perfectly legible
If the codes have been produced using ink-jet printers, dot peening machines, or lasers
(for example), the code elements may not be joined together seamlessly. In this case,
the readability of the codes can be improved by expanding the code elements.
NOTE
The value should be increased in stages until the code can be read successfully.
136 EAN 128
If the EAN 128 parameter is activated, decoding is enabled for the relevant code type.
(This requires the Pharmacode code type to be deactivated.)
NOTE
As only activated code types are processed, the processing speed can be increased by
specifically activating/deactivating the necessary code types.
•
Code name: EAN 128 (4-value)
•
Character set: Alphanumeric (ASCII) with three switchable character sets
°
Character set A: Digits, upper-case letters, and special characters
°
Character set B: Digits, upper-case and lower-case letters
°
Character set C: Double-density digits
•
Structure: FNC1, characters, check digit
•
Intrinsic safety: High
•
Spatial requirements: Low
•
Standard: ISO/IEC 15417
•
Areas of application: Identification of durable consumer goods
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
53
Subject to change without notice
