90 Codabar
If the Codabar parameter is activated, decoding is activated for the corresponding code
type. The configuration tab for the corresponding code type can be seen and opened in
SOPAS ET.
NOTE
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
•
Code name: Codabar (two-value)
•
Character set: 16 alphanumeric characters (10 digits, 6 special characters)
•
Structure: 7 code elements (4 bars, 3 gaps); start character (A, B, C, or D), code
content, stop character (A, B, C, or D)
•
Intrinsic safety: Low
•
Spatial requirements: Variable
•
Areas of application: Parcel and postal service
•
Standard: EN 798 bar coding
91 Code 128
If the Code 128 parameter is activated, decoding is enabled for the relevant code type.
(This requires the Code 128 code type to be deactivated.)
NOTE
As only activated code types are processed, the processing speed can be increased by
specifically activating/deactivating the necessary code types.
•
Code name: Code 128 (4-value)
•
Character set: Alphanumeric (ASCII) with three switchable character sets and one
check digit
°
Character set A: Digits, upper-case letters, special characters, and ASCII con‐
trol characters
°
Character set B: Digits, upper-case and lower-case letters, special characters,
and escape characters
°
Character set C: 100 pairs of digits (00 to 99) and FNC1 special character
•
Structure: Start symbol, useful information, check digit, stop symbol (11 modules
per symbol, each with 3 bars and 3 gaps)
•
Intrinsic safety: Very high (self-checking: even number of bars, uneven number of
gaps)
•
Spatial requirements: Largest possible number of characters per centimeter
•
Standard: ISO/IEC 15420
•
Areas of application: All areas, as UCC 128/EAN 128 in retail
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
41
