198 GS1 DataBar
If the GS1 DataBar parameter is activated, decoding is activated for the DataBar 14,
DataBar Expanded, and DataBar Limited activated code types. (This requires the GS1
DataBar code type to be deactivated.)
NOTE
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
199 GS1 Format
The control characters in the GS1 Data Matrix code format can be replaced with alter‐
native, user-specific characters under the GS1 Format group. Control characters in the
GS1 Data Matrix code format are used at the start of the code to identify the code for‐
mat and within the code to classify the data groups. The user-specific characters are
entered as hexadecimal values via the keyboard, clipboard, or the ADD VARIABLE OR CON‐
STANT button.
200 GTIN 13 / EAN 13
If the GTIN 13 / EAN 13 parameter is activated, decoding is enabled for the relevant
code type.
NOTE
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
•
Code name: GTIN 13 / EAN 13 (European Article Numbering) (4-value)
•
Character set: 13 numeric characters (check digits: last two characters)
•
Structure: 2 characters for country prefix (in accordance with GS1 standards), 8
characters for the manufacturer and article (in accordance with GS1 standards), 2
characters as check digits
•
Intrinsic safety: High
•
Spatial requirements: Low
•
Standard: DIN/EN 797
•
Areas of application: Foodstuffs and consumer goods in Europe
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
75
