Code IDs for bar codes
•
a, CODABAR
•
b, CODE39
•
c, UPC
•
d, EAN
•
e, INTERLEAVED25
•
g, MSI CODE
•
i, CODE93
•
j, CODE128
•
l, PLESSY
•
n, EAN 128
•
o, PHARMA
•
p, GS1 DataBar Expanded
•
r, PDF417
•
s, QR CODE
•
t, TELEPEN
•
u, GS1 DataBar Limited
•
w, MAXICODE
•
y, GS1_DATABAR
•
z, AZTEC
•
<, CODE32 (6 digit C39 decodes as C32)
50 Base COB-ID for ReadResult PDOs
The Base COB-ID for ReadResult PDOs parameter defines the CAN identifier of the first
transmit process data object (TPDO), which used to transmit the reading result.
When reading results are transmitted via process data objects (PDOs), the reading
result is distributed across several PDOs that are sent to the PLC one after the other.
The identifier for the first PDO must be configured; subsequent PDOs have consecutive
identifiers.
51 Baud rate
The maximum transmission rate for data sent by the sensor to the host can be adjusted
via the Baud rate parameter.
The value is specified in baud. This value defines the number of signal changes that
can take place via the interface per second. Depending on the protocol, up to four bits
can be transmitted per signal change (e.g., with 2,400 baud: up to 9,600 bits/second).
52 Baud rate
The maximum transmission rate can be adjusted via the Baud rate parameter.
The value is specified in bits/s.
NOTE
All devices on the CAN network must run at the same data baud rate. The maximum
length of cable for the network is dependent on the baud rate.
SOPAS PARAMETER OVERVIEW
30
O N L I N E H E L P | Lector62x 8013778/YPV6/2016-01-14 | SICK
Subject to change without notice
