379 UCC/GS1-128 Emulation
If the GS1 DataBar parameter is activated, decoding is activated for the DataBar 14,
DataBar Expanded, and DataBar Limited activated code types. (This requires the GS1
DataBar code type to be deactivated.)
NOTE
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
380 Subfolder Good Read / No Read
If the Subfolder Good Read / No Read parameter is activated, the images are stored in
two different subfolders so that the reading result can be analyzed more easily (GOOD
READ or NO READ).
381 UPC / GTIN / EAN
If the UPC / GTIN / EAN parameter is activated, decoding is jointly enabled for the fol‐
lowing code types: UPC A, UPC E, GTIN 8 / EAN 8, and GTIN 13 / EAN 13. The configu‐
ration tab for the corresponding code types can be seen and opened in SOPAS ET.
NOTE
As only activated code types are processed, you can increase the processing speed by
deactivating the code types that are not being used.
382 UPC
The UPC group can be used to activate or deactivate the UPC A, UPC E, and UPC E
extended code types.
383 UPC A
If the UPC A parameter is activated, decoding is enabled for the relevant code type.
NOTE
As only activated code types are processed, the processing speed can be increased by
specifically activating/deactivating the necessary code types.
•
Code name: UPC A (Universal Product Code) (4-value)
•
Character set: 12 numeric characters (check digit: last character)
•
Structure: 2 characters for country prefix, 9 characters for the manufacturer and
article, 1 character as the check digit
•
Intrinsic safety: High
•
Spatial requirements: Low
•
Standard: DIN/EN 797
•
Areas of application: Foodstuffs and consumer goods in the USA and Canada
SOPAS PARAMETER OVERVIEW
124
O N L I N E H E L P | Lector62x 8013778/YPV6/2016-01-14 | SICK
Subject to change without notice
