18 General Match-code teach-in settings
The General Match-code teach-in settings group contains the parameters for teaching
in the match codes.
The two match codes are stored in the Match-code teach-in 1 and Match-code teach-in
2 (Additional) groups and can be subsequently customized.
19 Alpha
The device's Alpha angle in relation to the code and trigger position is defined under
the Alpha parameter.
Example: Angle set to 90° or 270°. The reading is taken perpendicular to the convey‐
ing direction.
20 Alternate Score
If the Alternate Score parameter is activated, the calculation of the score value is opti‐
mized.
This parameter is used to increase the score values of the Alternate Classifier.
NOTE
The optimization option is only available for the Alternate Classifier.
21 Change camera settings
If the Change camera settings parameter is activated, the brightness and contrast are
adjusted via the AUTO-SETUP function. This function is accessed by pressing the pushbut‐
tons on the sensor.
22 Change code settings
If the Change code settings parameter is activated, the code settings for the DATA MATRIX
code type are adjusted via the AUTO-SETUP function. This function is accessed by pressing
the pushbuttons on the sensor.
23 Change reading distance
If the Change reading distance parameter is activated, the reading distance is adjusted
via the AUTO-SETUP function. This function is accessed by pressing the pushbuttons on
the sensor.
24 Number of Images
The Number of Images parameter is used to set the number of images that are cap‐
tured in INDIVIDUAL IMAGES capturing mode. The number of images captured depends on
the reading gate length.
25 Number of mapped RPDO bytes
The Number of mapped RPDO bytes parameter defines the scope of the receive proc‐
ess data objects (RPDOs) that can be received by the script program.
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
17
Subject to change without notice
