Wizard
Pressing the START WIZARD button launches a dialog box for fully configuring the device as
a node on a SICK network running in the master/slave operating mode. The wizard pro‐
vides the parameters required for configuring the CAN interface, device network func‐
tions, output control, and object trigger control. The values you enter in the wizard are
applied to the relevant parameter groups and tabs once configuration is complete.
249 Match code
The Match code tab contains the parameters for teaching in match codes (set codes).
Codes read during operation are compared with the content of the match code. The cor‐
relation is displayed.
NOTE
So that this can happen, the first step is to ensure that the prerequisites for a success‐
ful read operation are in place by checking that the parameters on the Camera and Illu‐
mination tab have been set correctly.
NOTE
If a match code is to be activated after it has been taught in, the relevant condition
must be selected for the Condition for Good Read parameter, for example. If the con‐
tent of the codes that has been read does not match the active match code conditions,
the read operation is classed as unsuccessful (NO READ).
250 Match-code teach-in 1
The Match-code teach-in 1 group contains the parameters for teaching in match code
1.
NOTE
If a match code is to be activated after it has been taught in, the relevant condition
must be selected for the Condition for Good Read parameter, for example.
251 Match-code teach-in 2 (Additional)
The Match-code teach-in 2 (Additional) group contains the parameters for teaching in
match code 2.
NOTE
If a match code is to be activated after it has been taught in, the relevant condition
must be selected for the Condition for Good Read parameter, for example.
252 Check max. number of valid codes
If the Check max. number of valid codes parameter is activated, the system calculates
how many different codes there are and compares this number with a specified maxi‐
mum (Maximum).
This can be used, for example, to ensure that only the required codes are present on an
object.
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
89
Subject to change without notice
