11 Active
The data output of the SICK Visualization Platform can be activated via the Active
parameter.
NOTE
The device time must be set to operate the SVP.
12 Active
The event that activates the digital output is selected via the Active parameter.
•
SOPAS COMMAND: The output can be activated via a command. This allows defined
statuses to be displayed by a connected indicator lamp when a corresponding
command is issued by the control (PLC).
•
DEVICE READY: The output is activated as soon as the sensor is ready for use.
•
GOOD READ: The output is activated if the read operation was successful.
•
NO READ: The output is activated if the read operation was unsuccessful.
•
TEACH-IN 1 OK: The output is activated if the MATCH CODE TEACH-IN 1 has been success‐
fully taught in.
•
TEACH-IN 1 NOK: The output is activated if the MATCH CODE TEACH-IN 1 could not be suc‐
cessfully taught in.
•
TEACH-IN 2 OK: The output is activated if the MATCH CODE TEACH-IN 2 has been success‐
fully taught in.
•
TEACH-IN 2 NOK: The output is activated if the MATCH CODE TEACH-IN 2 could not be suc‐
cessfully taught in.
•
MATCH 1 CONDITION: The output is activated if the code that has been read corre‐
sponds to the MATCH 1 CONDITION match code.
•
MULTICODES1 CONDITION: The output is activated if the number of codes that have
been read corresponds to the number specified by the MULTICODES1 CONDITION.
•
TEACH-IN1 CONDITION: The output is activated if the code that has been read corre‐
sponds to the TEACH-IN1 CONDITION match code.
•
TEACH-IN2 CONDITION: The output is activated if the code that has been read corre‐
sponds to the TEACH-IN2 CONDITION match code.
13
Active Script
Scripts can be activated in the Active Script group.
14 Enable user I/O PDOs
If the Enable user I/O PDOs parameter is activated, user-defined process data objects
(PDOs) can be sent and received by a script program.
The user-defined PDOs are entries in the object directory that are reserved for scripts
and configured in the object directory. The reserved PDOs allow the script to receive
status changes from the CAN input modules and control CAN output modules by send‐
ing a PDO. This is how the communication bandwidth of the device is extended in terms
of its software. The reading device can use the extended communication bandwidth for
control tasks within its surrounding area, even if the required number of switching
inputs and outputs for the control process is not available.
15
Enable heartbeat
If the Enable heartbeat parameter is activated, a signal is output via the interface at
regular intervals (Heartbeat interval). In this way, the availability of the sensor can be
checked via the interface.
SOPAS PARAMETER OVERVIEW
8013778/YPV6/2016-01-14 | SICK O N L I N E H E L P | Lector62x
15
Subject to change without notice
