Peripheral boards
Settings
Table 3-146 TMCAS-2 (for selected countries only) – Jumper Functions
Jumper Function Setting
Pins 1–2 closed Pins 2–3 closed
X11 Sets the V.24 baud rate See Table 3-147
X12
X14
X13 Deletes the flash mem-
ory
Flash memory is deleted
(all sectors apart from U-
boot (firmware)).
Flash memory is not de-
leted.
(default setting)
X16 Resetting the card Reset performed. Reset not performed.
(default setting)
X17 Hardware watchdog Watchdog active.
(default setting)
Watchdog not active.
X24 Sets trunk impedance
for CAS interface 1
75 ohms
(default setting)
120 ohms
X25 Sets trunk impedance
for CAS interface 2
75 ohms
(default setting)
120 ohms
X999 Grounding: card / CAS
cable
Grounding for the card is
connected to the ground-
ing for the CAS cable.
Grounding for the card is
not connected to the
grounding for the CAS
cable.
(default setting)
Table 3-147 TMCAS-2 (for selected countries only) – Jumper for Setting the V.24 Baud
Rate
V.24 baud rate
(Kbps)
Jumper
X11 X12 X14
9.6
(default setting)
Open Open Open
19.2 Open Open Closed
38.4 Closed Open Closed
57.6 Open Closed Closed
115.2 Closed Closed Closed
9.6 All other configurations
