Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
108 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
MCP1StatSend := P#A8.0,
MCP1StatRec := P#A12.0,
MCP1BusAdr := 14,
MCP1Timeout := S5T#700MS,
MCPMPI:= TRUE,
NCCyclTimeout := S5T#200MS,
NCRunupTimeout := S5T#50S);
//INSERT USER PROGRAM HERE
END_ORGANIZATION_BLOCK
Call example for SINUMERIK 840D
An example call for the FB 1 in OB 100 appears below. This example is part of the diskette
with basic program for 840D.
ORGANIZATION_BLOCK OB 100
VAR_TEMP
OB100_EV_CLASS : BYTE ;
OB100_STRTUP : BYTE ;
OB100_PRIORITY : BYTE ;
OB100_OB_NUMBR : BYTE ;
OB100_RESERVED_1 : BYTE ;
OB100_RESERVED_2 : BYTE ;
OB100_STOP : WORD ;
OB100_RESERVED_3 : WORD ;
OB100_RESERVED_4 : WORD ;
OB100_DATE_TIME : DATE_AND_TIME;
END_VAR
BEGIN
CALL FB 1, DB 7 (
MCPNum := 1,
MCP1In := P#E0.0,
MCP1Out := P#A0.0,
MCP1StatSend := P#A8.0,
MCP1StatRec := P#A12.0,
MCP1BusAdr := 6,
MCP1Timeout := S5T#700MS,
MCP1Cycl := S5T#200MS,
NC-CyclTimeout := S5T#200MS,
NC-RunupTimeout := S5T#50S);
//INSERT USER PROGRAM HERE
END_ORGANIZATION_BLOCK
