Basic logic functions: Tool Offset (W1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
185
Examples
4
4.1 Toolholder with orientation capability
4.1.1 Example: Toolholder with orientation capability
Requirement
The following example uses a toolholder, which is described fully by a rotation about the Y
axis. It is therefore sufficient to enter only one value to define the rotary axis (block N20).
Blocks N50 to N70 describe an end mill with radius 5 mm and length 20 mm.
Block N90 defines a rotation of 37 degrees about the Y axis.
Block N120 activates the tool radius compensation and all settings are made to describe the
compensation in the following blocks with a rotation of 37 degrees about the Y axis.
N10
; Definition of toolholder 1
N20 $TC_CARR8[1] = 1
; Component of the first rotary axis in the Y
direction
N30
N40
; Definition of tool-compensation memory T1/D1
N50 $TC_DP1[1,1] = 120
; End mill
N60 $TC_DP3[1,1] = 20
; Length 1
N70 $TC_DP6[1,1] = 5
; Radius
N80
N90 ROT Y37
; 37-degree rotation about y axis
N100
N110 X0 Y0 Z0 F10000
N120 G42 CUT2DF TCOFR TCARR = 1 T1 D1 X10
N130 X40
N140 Y40
N150 X0
N160 Y0
N170 M30
