Data lists
5.2 Setting data
Basic logic functions: Feeds (V1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
67
5.2 Setting data
5.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42000 THREAD_START_ANGLE Start angle for thread
42010 THREAD_RAMP_DISP Runin and runout path of feed axis with thread cutting
42100 DRY_RUN_FEED Dry run feed
42101 DRY_RUN_FEED_MODE Dry run feed mode
42110 DEFAULT_FEED Default value for path feed
42600 JOG_FEED_PER_REV_SOURCE In the JOG mode, revolutional feedrate for geometry
axes on which a frame with rotation acts
43300 ASSIGN_FEED_PER_RES_SOURCE Revolutional feedrate for positioning axes
5.2.2 Axis/spindle-specific setting data
Number Identifier: $SA_ Description
43210 SPIND_MIN_VELO_G25 Minimum spindle speed
43220 SPIND_MAX_VELO_G26 Maximum spindle speed
43230 SPIND_MAX_VELO_LIMS Spindle-speed limitation with G96
