Detailed description
2.13 Signal/data descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
269
2.13.4 Message signals in DB 2
General
DB2 allows the user to display the messages for individual signals on the operator panel
front. As the lists of interface signals show, signals are divided into predefined groups. In the
event of incoming and outgoing messages and message acknowledgements, the number
entered in the message number column is transferred to the PCU. Text can be stored for
each message number.
References:
/IAD/Installation and Start-Up Guide; Message Numbers
Note
The number of user areas can be parameterized via FB1.
After the configuration has been modified (FB1: MsgUser) DB2/DB3 must be deleted.
Channel areas in DB2
Area Address Message number
Channel 1 DBX0.0 - DBX11.7 510.000 -- 510.231
Channel 1, geo axes DBX12.0 - DBX17.7 511.100 - 511.315
Channel 2 DBX18.0 - DBX29.7 520.000 - 520.231
Channel 2, geo axes DBX30.0 - DBX35.7 521.100 - 521.315
Channel 3 DBX36.0 - DBX47.7 530.000 - 530.231
Channel 3, geo axes DBX48.0 - DBX53.7 531.000 - 531.315
Channel 4 DBX54.0 - DBX65.7 540.000 - 540.231
Channel 4, geo axes DBX66.0 - DBX71.7 541.100 - 541.315
Channel 5 DBX72.0 - DBX83.7 550.000 - 550.231
Channel 5, geo axes DBX84.0 - DBX89.7 551.100 - 551.315
Channel 6 DBX90.0 - DBX101.7 560.000 - 560.231
Channel 6, geo axes DBX102.0 - DBX107.7 561.100 - 561.315
Channel 7 DBX108.0 - DBX119.7 570.000 - 570.231
Channel 7, geo axes DBX120.0 - DBX125.7 570.100 - 571.315
Channel 8 DBX126.0 - DBX137.7 580.000 - 580.231
Channel 8, geo axes DBX138.0 - DBX143.7 581.100 - 581.315
Channels 9 and 10 are not currently
implemented
