Basic logic functions: Acceleration (B2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
61
Data lists
5
5.1 Machine data
5.1.1 Channelspecific machine data
Number Identifier: $MC_ Description
20150 GCODE_RESET_VALUES Initial setting of G groups
20500 CONST_VELO_MIN_TIME Minimum time with constant velocity
20600 MAX_PATH_JERK Pathrelated maximum jerk
20602 CURV_EFFECT_ON_PATH_ACCEL Influence of path curvature on dynamic path response
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
5.1.2 Axis/spindlespecific machine data
Number Identifier: $MA_ Description
32000 MAX_AX_VELO Maximum axis velocity
32300 MAX_AX_ACCEL Maximum axis acceleration
32310 MAX_ACCEL_OVL_FACTOR Overload factor for velocity jump
32320 DYN_LIMIT_RESET_MASK Reset behavior of dynamic limits
32400 AX_JERK_ENABLE Axial jerk limitation
32402 AX_JERK_MODE Filter type for axial jerk limitation
32410 AX_JERK_TIME Time constant for axial jerk filter
32420 JOG_AND_POS_JERK_ENABLE Enabling axial jerk limitation
32430 JOG_AND_POS_MAX_JERK Max. axial jerk for JOG and POS
32431 MAX_AX_JERK Maximum axis jerk for path motion
32432 PATH_TRANS_JERK_LIM Max. axial jerk of a geometry axis at block boundary
