Detailed description
2.6 Block search Type 5 SERUPRO
Basic logic functions: Mode group, channel, program operation, reset response (K1)
50 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.6 Block search Type 5 SERUPRO
SERUPRO
The "search via program test" is from now on referred to as SERUPRO. This acronym has
been derived from "SEarch RUn by PROgram test".
Function
SERUPRO can be used for a cross-channel block search.
This search permits a block search with calculation of all necessary data from the previous
history, so as to acquire all previously valid status data for a particular overall NC status. The
PLC is hereby updated to the current status.
The NC is operated in "Program test" mode during this block search so that interactions
between a channel and synchronized actions or between several channels, can take place
within an NCU.
Channels
In combination with the HMI, SERUPRO is provided for the following channels:
• For the current SERUPRO channel only (1)
• For all channels with the same workpiece name as the SERUPRO channel (2)
• For all channels with the same mode group as the SERUPRO channel (3)
• For all channels of the NCU (4)
The scope of channels for SERUPRO is selected by means of configuration file
maschine.ini, in Section [BlockSearch]:
Section [BlockSearch] Enable search function for HMI and select search configuration
SeruproEnabled=1 ;SERUPRO softkey available for HMI. Default value is (1)
SeruproConfig=1 ;Number (1) to (4) of above indicated channel grouping. Default value is (1)
All other channels started with SERUPRO are operated in "SelfActing SERUPRO" mode.
Only the channel in which a target block has been selected can be started with a block
search in SERUPRO mode.
