Basic logic functions: PLC Basic program powerline (P3 pl)
128 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.12.4.1 Overview of available PI services
Overview of PI services
The following section provides an overview of the PI services that can be started from the
PLC. The meaning and application of the general FB 4 input variables (Unit, Addr ..., WVar
...) depend on the individual PI service concerned.
available SINUMERIK PI service Function
FM-NC 810/840D
ASUB Assign interrupt * *
CANCEL Execute cancel * *
CONFIG Reconfiguration of
tagged machine data
* *
DIGION Digitizing on *
DIGIOF Digitizing off *
FINDBL Activate block search * *
LOGIN Activate password * *
LOGOUT Reset password * *
NCRES Trigger NC RESET. *
SELECT Select program for processing for one channel * *
SETUDT Sets the current user data to active *
PI service Tool management function
CRCEDN Create new cutting edge *
CREACE Create cutting edge * *
CREATO Generate tool * *
SETUFR Activate user frames * *
DELECE Delete a cutting edge *
DELETO Delete tool * *
MMCSEM Semaphores for various PI services *
TMCRTO Create tool *
TMFDPL Empty location search for loading *
TMFPBP Empty location search *
TMGETT T-number for the previous tool identifier with Duplo
number
*
TMMVTL Prepare magazine location for loading, unload tool *
TMPOSM Position magazine location or tool *
TMPCIT Set increment value for workpiece counter *
TMRASS Reset active status *
TRESMO Reset monitoring values *
TSEARC Complex search using search screen forms *
x: PI service is available
