Data lists
5.1 Machine data
Basic logic functions: Tool Offset (W1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
201
Number Identifier: $MC_ Description
20252 CUTCOM_MAXNUM_SUPPR_BLOCKS Maximum number of blocks with compensation
suppression
20256 CUTCOM_INTERS_POLY_ENABLE Intersection process possible for polynomials
20270 CUTTING_EDGE_DEFAULT Selected cutting edge after tool change
20272 SUMCORR_DEFAULT Number for activating a new cutting edge
compensation
20360 TOOL_PARAMETER_DEF_MASK Defines the effect of tool parameters
20390 TOOL_TEMP_COMP_ON Activation of temperature compensation for tool length
20392 TOOL_TEMP_COMP_LIMIT Maximum temperature compensation for tool length
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
21080 CUTCOM_PARALLEL_ORI_LIMIT Limit angle between path tangent and tool orientation
with
3D tool radius compensation
22530 TOCARR_CHANGE_M_CODE M code for change of toolholder
22550 TOOL_CHANGE_MODE New tool compensations with M function
22560 TOOL_CHANGE_M_CODE M function for tool change
22562 TOOL_CHANGE_ERROR_MODE Error response on programmed tool change
24558 TRAFO5_JOINT_OFFSET_PART_1 Vector of kinematic offset in table, transformation 1
24658 TRAFO5_JOINT_OFFSET_PART_2 Vector of kinematic offset in table, transformation 2
28085 MM_LINK_TOA_UNIT Assignment of TO unit to a channel
5.1.3 Axis/spindlespecific machine data
Number Identifier: $MA_ Description
32750 TEMP_COMP_TYPE Temperature compensation type
