Detailed description
2.13 Signal/data descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
267
2.13.3 G Functions
General
The G functions programmed in the part program, ASUB or synchronized actions are
channel specifically transferred from the NC to the PLC:
• G functions from channel 1: DB21
• G functions from channel 2: DB22
• etc.
The signal length is one PLC cycle.
POWER ON
After POWER ON, the value zero, i.e., active G groups undefined, is specified in the NC/PLC
interface for all G groups.
Part program-End or Abort
After part program end or abort, the last state of the G group is retained.
NC-START
After NC-START the values specified in the machine data:
MD22510 $NC_ GCODE_GROUPS_TO_PLC
specified 8 G-groups corresponding to the basic setting done via the machine data, as well
as the values programmed in the part program, are overwritten.
Addresses in DB21, ... Variables Type Basic position Comment
DBB 208
G_FKT_GR_1
BYTE 0 Active G function of group 1
DBB 209
G_FKT_GR_2
BYTE 0 Active G function of group 2
DBB 210
G_FKT_GR_3
BYTE 0 Active G function of group 3
DBB 211
G_FKT_GR_4
BYTE 0 Active G function of group 4
DBB 212
G_FKT_GR_5
BYTE 0 Active G function of group 5
DBB 213
G_FKT_GR_6
BYTE 0 Active G function of group 6
DBB 214
G_FKT_GR_7
BYTE 0 Active G function of group 7
DBB 215
G_FKT_GR_8
BYTE 0 Active G function of group 8
DBB 216
G_FKT_GR_9
BYTE 0 Active G function of group 9
DBB 217
G_FKT_GR_10
BYTE 0 Active G function of group 10
DBB 218
G_FKT_GR_11
BYTE 0 Active G function of group 11
DBB 219
G_FKT_GR_12
BYTE 0 Active G function of group 12
DBB 220
G_FKT_GR_13
BYTE 0 Active G function of group 13
DBB 221
G_FKT_GR_14
BYTE 0 Active G function of group 14
DBB 222
G_FKT_GR_15
BYTE 0 Active G function of group 15
DBB 223
G_FKT_GR_16
BYTE 0 Active G function of group 16
DBB 224
G_FKT_GR_17
BYTE 0 Active G function of group 17
DBB 225
G_FKT_GR_18
BYTE 0 Active G function of group 18
DBB 226
G_FKT_GR_19
BYTE 0 Active G function of group 19
DBB 227
G_FKT_GR_20
BYTE 0 Active G function of group 20
DBB 228
G_FKT_GR_21
BYTE 0 Active G function of group 21
