Detailed description
2.1 Axes
Basic logic functions: Axes, coordinate systems, frames (K2)
26 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.1.9 Main axes
Significance
A main axis is an axis that is interpolated by the main run.
This interpolation can be started as follows:
• From synchronized actions
(as command axes due to an event via block-related, modal or static synchronized
actions)
• From the PLC via special function blocks in the PLC basic program
(named as a concurrent positioning axis or a PLC axis)
• Via the setting data or from the part program
(as an asynchronous or block-synchronous oscillating axis)
Channel control
An axis interpolated by the main axis reacts in terms of:
• NC STOP
• Alarm handling
• Program control
• End of program
• RESET
Note
The response at the end of the program varies. The axis movement need not always be
completed and, therefore, may carry on beyond the end of the program.
Application
Certain axes in the main run can be decoupled at the channel response triggered by the NC
program sequence and controlled from the PLC. These axes are also interpolated in the
main run and respond independently for the channel and program sequence.
A PLC-controlled axis can then be controlled independently by the NC. This concerns the
following actions:
• The sequence for canceling the axis (equivalent to delete distancetogo)
• Stopping or interrupting the axis
• Continuing the axis (continue sequence of motion)
• Resetting the axis to its basic status
