Data lists
5.2 Setting data
Basic logic functions: Continuouspath Mode, Exact Stop, LookAhead (B1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
63
5.2 Setting data
5.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42465 SMOOTH_CONTUR_TOL Max. contour deviation on rounding
42466 SMOOTH_ORI_TOL Max. deviation of the tool orientation on rounding
42470 CRIT_SPLINE_ANGLE Limit angle for spline and polynomial interpolation and
compressor
5.3 Signals
5.3.1 Signals from channel
DB number Byte.Bit Description
21, ... 36.3 All axes stationary
5.3.2 Signals to axis/spindle
DB number Byte.Bit Description
31, ... 60.6 Position reached with exact stop coarse
31, ... 60.7 Position reached with exact stop fine
