5.3 System variables
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
153
5.3 System variables
Names Description
$AA_ETRANS[axis] Offset value zero offset external
$AA_IBN[axis] Actual value in basic zero coordinate system (BZS)
$AA_IEN[axis] Actual value in settable zero point coordinate system (ENS)
$AA_OFF[axis] Overlaid motion for programmed axis
$AC_DRF[axis] DRF offset (differential resolver function)
$AC_JOG_COORD Changeover of the manual operation coordinate system
$P_ACSFRAME Current frame for defining the ENS (ACS)
$P_ACTBFRAME Current chained total basic frame
$P_ACTFRAME Current total frame
$P_BFRAME Current first basic frame in the channel. Corresponds to $P_CHBFRAME
$P_CHBFR[n] Channel basic frames, activated via G500, G54 to G599
$P_CHBFRAME[n] Current basic frame in channel
0 to 15 NCU basic frames can be set through:
MD28081 MM_NUM_BASE_FRAMES
$P_CHBFRMASK Bit mask for definition of channelspecific basic frames
$P_CHSFRMASK Bit mask for activating system frames in data management
$P_CYCFR System frame for cycles
$P_CYCFRAME Current system frame for cycles
$P_EXTFR System frame for zero offset external in data management
$P_EXTFRAME Current system frame for zero offset external
$P_IFRAME Current settable frame
$P_ISO1FR System frame for ISO G51.1 mirroring
$P_ISO2FR System frame for G68 2DROT (ISO)
$P_ISO3FR System frame for G68 3DROT (ISO)
$P_ISO4FR System frame for G51 scale (ISO)
$P_ISO1FRAME Current system frame for ISO G51.1 mirroring
$P_ISO2FRAME Current system frame for G68 2DROT (ISO)
$P_ISO3FRAME Current system frame for G683DROT (ISO)
$P_ISO4FRAME Current system frame for G51 scale (ISO)
$P_NCBFR[n] NCU basic frames, activated via G500, G54 to G599
$P_NCBFRAME[n] Current NCU basic frame
0 to 15 NCU basic frames can be set through:
MD18602 MM_NUM_GLOBAL_BASE_FRAMES
$P_NCBFRMASK Bit mask for definition of NCU global basic frames
$P_PARTFR System frame for TCARR and PAROT in data management
$P_PARTFRAME Current system frame for TCARR and PAROT with an orientational toolholder
$P_PFRAME Current programmable frame
$P_SETFR System frame for PRESET and scratching in data management
$P_SETFRAME Current system frame for PRESET and scratching
