Detailed description
2.9 Assignment overview
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
77
2.9.3 Assignment: DB
Note
Only as many data blocks as are required according to the NC machine data configuration
are set up.
Overview of data blocks
DB no. Name Name Packa
ge
1 Reserved for Siemens BP
2-5 PLC-MELD PLC messages BP
6-8 Basic program
9 NC-COMPILE Interface for NC compile cycles BP
10 NC INTERFACE Central NCK interface BP
11 Mode group 1 Interface mode group BP
12 Computer link and transport system interface
13-14 Reserved for basic program
15 Basic program
16 PI Service definition
17 Version identifier
18 Reserved for basic program
19 HMI interface
20 PLC machine data
21 - 30 CHANNEL 1 ... n Interface NC channels BP
BP 31 - 61 AXIS 1 ... m Interfaces for axes/spindles
or free for user assignment
62 - 70 Free for user assignment
71 - 74 Tool management BP
75 - 76 M group decoding
77 Data block for MCP signals
78 - 80 Reserved for Siemens
81 - 999
1)
see below: ShopMill, ManualTurn
1000 – 1099 Reserved for Siemens
1100 -
upper limit
Free for user assignment
1)
Note:
The actual upper limit of the block number (DB) depends on the PLC CPU on which the selected
NCU is located. The data blocks of channels, axes/spindles and tool management functions that are
not activated may be assigned as desired by the user.
