Basic logic functions: Auxiliary Function Output to PLC (H2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
63
Data lists
5
5.1 Machine data
5.1.1 NC-specific machine data
Number Identifier: $MN_ Description
10713 M_NO_FCT_STOPRE M function with preprocessing stop
10714 M_NO_FCT_EOP M function for spindle active after NC RESET
11100 AUXFU_MAXNUM_GROUP_ASSIGN Maximum number of user-defined auxiliary functions
per channel
11110 AUXFU_GROUP_SPEC[n], Group-specific output behavior
5.1.2 Channelspecific machine data
Number Identifier: $MC_ Description
20110 RESET_MODE_MASK Definition of control initial setting after part program
start.
20112 START_MODE_MASK Definition of control initial setting after powerup and
on RESET or at end of part program
20270 CUTTING_EDGE_DEFAULT Basic setting of tool cutting edge without programming
20800 SPF_END_TO_VDI Subprogram end to PLC
22000 AUXFU_ASSIGN_GROUP Auxiliary function group
22010 AUXFU_ASSIGN_TYPE Type of auxiliary function
22020 AUXFU_ASSIGN_EXTENSION Auxiliary function extension
22030 AUXFU_ASSIGN_VALUE Auxiliary function value
22035 AUXFU_ASSIGN_SPEC Output specification (user-def. AuxFu)
22040 AUXFU_PREDEF_GROUP Predefined auxiliary function groups
22050 AUXFU_PREDEF_TYPE Predefined auxiliary function type
22060 AUXFU_PREDEF_EXTENSION Predefined auxiliary function extension
22070 AUXFU_PREDEF_VALUE Predefined auxiliary function value
