5.2 Setting data
Basic logic functions: Acceleration (B2)
62 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Number Identifier: $MA_ Description
32433 SOFT_ACCEL_FACTOR Scaling of acceleration limitation for SOFT
32434 G00_ACCEL_FACTOR Scaling of acceleration limitation for G00
32435 G00_JERK_FACTOR Scaling of axial jerk limitation for G00
35220 ACCEL_REDUCTION_SPEED_POINT Speed for reduced acceleration
35230 ACCEL_REDUCTION_FACTOR Acceleration reduction factor
35240 ACCEL_TYPE_DRIVE "DRIVE" acceleration characteristic curve: ON/OFF
35242 ACCEL_REDUCTION_TYPE Type of acceleration reduction
5.2 Setting data
5.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42500 SD_MAX_PATH_ACCEL Max. path acceleration
42502 IS_SD_MAX_PATH_ACCEL Analysis of SD 42500: ON/OFF
42510 SD_MAX_PATH_JERK Max. path-related jerk
42512 IS_SD_MAX_PATH_JERK Analysis of SD 42510: ON/OFF
5.3 System variables
Identifier Description
$AC_PATHACC Path acceleration for real-time events
$AC_PATHJERK Path jerk for real-time events
