Data lists
5.2 Signals
Basic logic functions: Reference Point Approach (R1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
61
5.2 Signals
5.2.1 Signals to BAG
DB number Byte.Bit Name
11 0.7 Mode group RESET
11 1.2 Machine function REF
5.2.2 Signals from BAG
DB number Byte.Bit Name
11 5.2 Active machine function REF
5.2.3 Signals to channel
DB number Byte.Bit Name
21, ... 1.0 Activate referencing
21, ... 28.7 OEM channel signal (HMI → PLC) REF
5.2.4 Signals from channel
DB number Byte.Bit Name
21, ... 33.0 Referencing active
21, ... 35.7 Reset
21, ... 36.2 All axes referenced
