Basic logic functions: Transverse axes (P1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
5
Brief description
1
Within the framework of "turning" technology, the transverse axis refers to the machine axis
that travels perpendicular to the axis of symmetry of the spindle, in other words, to
longitudinal axis Z.
Definition
Every geometry axis of a channel can be defined as a transverse axis.
However, only exactly one transverse axis can be defined per channel.
A transverse axis is a linear axis for the following functions, which can be permitted and
activated at the same time or separately:
• Programming and display in the diameter
• Reference axis for constant cutting speed G96/G961/G962
Overview of the transverse axes functions
Diameter programming and reference axis for G96/G961/G962 can be active for different
transverse axes (several transverse axes in a channel).
Functional decoupling of diameter programming and reference axis
Programming and
display in the diameter
Reference axis for
G96/G961/G962
Comment
Geometry axis Linear channel
axes
Geometry axis Permitted axis type
one m of 3 m of n one one
of 3
Selection in the
channel
Channel
$
MC_MD
20100
Axis
$MA_MD3460
BASE_FUNCTION_MASK
Channel
$MC_MD20100
_DIAMETER_AX_DEF
Specific effect
machine data axis
functions
DIAM*
channel-specific modal
G group 29
SCC[AX]
channel-specific modal reference
axis for G96/G961/G962
Programming
DIAM*A[AX]
axis-specific modal
Acceptance during
axis replacement
DAC, DIC; RAC, RIC axis-specific non-
modal only programming
axis-specific non-
modal
DIAM*: DIAMOF, DIAMON, DIAM90, DIAMCYCOF
DIAM*A[AX]:
DIAMOFA[AX], DIAMONA[AX], DIAM90A[AX], DIACYCOFA[AX], DIAMCHANA[AX]
AX: Axis identifier for geometry/channel or machine axis identifier
Rotary axes are not permitted to serve as transverse axes.
