Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
180 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Call example
FUNCTION FC 99: VOID
TITLE =
VERSION : 0.0
BEGIN
NETWORK
TITLE = NETWORK
CALL FB 29, DB 80 (
Func
:= 1,
Signal_1 :=M 100.0,
Signal_2 :=M 100.1,
Signal_3 :=M 100.2,
Signal_4 :=M 100.3,
Signal_5 :=M 10.4,
Signal_6 :=M 100.5,
Signal_7 :=M 100.6,
Signal_8 :=M 100.7,
NewCycle := TRUE,
Var1 := MB 100,
BufDB := 81,
ClearBuf :=M 50.0);
END_FUNCTION
2.12.11 FC 2: GP_HP Basic program, cyclic section
Description of Functions
The complete processing of the NCKPLC interface is carried out in cyclic mode. In order to
minimize the execution time of the basic program, only the control/status signals are
transmitted cyclically; transfer of the auxiliary functions and G functions only takes place
when requested by the NCK.
Declaration
FUNCTION FC 2: VOID
//No parameters
