Data lists
5.3 Signals
Basic logic functions: Various NC/PLC interface signals and functions (A2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
53
DB number Byte.Bit Description
19 24.7 RS232 ON (Acknowledgment byte for current RS232 status)
19 26.0 Error (Part program handling status)
19 26.1 O.K. (Part program handling status)
19 26.3 Active (Part program handling status)
19 26.5 Unload (Part program handling status)
19 26.6 Load (Part program handling status)
19 26.7 Select (Part program handling status)
19 42.0 FC9: Measure in JOG mode
19 45.0 FC9 Out: Active
19 45.1 FC9 Out: Done
19 45.2 FC9 Out: Error
19 45.3 FC9 Out: StartErr
5.3.5 Signals to channel
DB number Byte.Bit Description
21, ... 6.2 Delete distancetogo (channelspecific)
5.3.6 Signals from channel
DB number Byte.Bit Description
21, ... 36.6 Channelspecific NCK alarm is active
21, ... 36.7 NCK alarm with processing stop present
21, ... 318.7 Overstore active
5.3.7 Signals to axis/spindle
DB number Byte.Bit Description
31, ... 1.3 Axis/spindle disable
31, ... 1.4 Follow-up mode
31, ... 1.5 Position measuring system 1
31, ... 1.6 Position measuring system 2
