Basic logic functions: Diagnostic tools (D1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
7
Detailed description
2
2.1 Description of diagnostic tools
Scope
The Function Manual deals with displays of the user interface, system functions, procedures
for determining system statuses and, if necessary, measures for avoiding undesirable
conditions for the NC control, PLC and drives.
General
Alarm and signal status displays
The currently active or not yet acknowledged alarms and messages are displayed in the
Diagnostics operating area.
Alarm log
The alarm log contains the alarms that have occurred and the time. Detailed information on
the individual alarms can be found in:
References:
/DA/ Diagnostics Manual or in the case of systems with HMI Advanced see Online Help.
Note
The corresponding explanations for alarms and messages which the machine tool
manufacturer issues (range of values ......),
can be found in the machine tool manufacturer's documentation.
Alarm handler
Application
The alarm handler provides an infrastructure for activating and managing alarms on the
NCK.
