Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
260 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Description of the formal parameters
The table below shows all formal parameters of the "HPU_MCP" function.
Signal Type Type Value range Remark
BAGNo I BYTE 0 - b#16#0A
and
b#16#10 - b#16#1A
No. of mode group to which the mode signals
are transferred.
BAGNo >= b#16#10 means access to the
second machine control panel.
ChanNo I BYTE 0 - B#16#0A Channel no. for the channel signals
2.12.28.2 MCP selection signals to the user interface
Operating modes and machine functions
Source:
MCP key
Destination:
Interface DB (parameter ModeGroupNo)
representation for mode group 1
AUTOMATIC DB11, ... DBX0.0
MDA DB11, ... DBX0.1
JOG DB11, ... DBX0.2
REPOS DB11, ... DBX1.1
REF DB11, ... DBX1.2
TEACH IN DB11, ... DBX1.0
INC 1 ... 10 000, INC Var. (starting from SW
5)
DB11, ... DBB2, Bit 0 to 5
Source:
MCP key
Destination:
Interface DB (parameter ChanNo)
INC 1 ... 10 000, INC Var. (till SW 4) DB21, ... DBB13, Bit 0 to 5
INC 1 ... 10 000, INC Var. (till SW 4) DB21, ... DBB17, Bit 0 to 5
INC 1 ... 10 000, INC Var. (till SW 4) DB21, ... DBB21, Bit 0 to 5
Source:
MCP key
Destination:
Interface DB (6-axis DB)
INC 1 ... 10 000, INC Var. (till SW 4) DB31, ... DBB5, Bit 0 to 5
