Data lists
5.1 Machine data
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
151
5.1.3 Channelspecific machine data
Number Identifier: $MC_ Description
20050 AXCONF_GEOAX_ASSIGN_TAB Assignment geometry axis to channel axis
20060 AXCONF_GEOAX_NAME_TAB Geometry axis name in channel
20070 AXCONF_MACHAX_USED Machine axis number valid in channel
20080 AXCONF_CHANAX_NAME_TAB Channel axis name/special axis name in channel
20110 RESET_MODE_MASK Definition of basic control settings after RESET/TP-
End)
20118 GEOAX_CHANGE_RESET Allow automatic geometry axis change
20126 TOOL_CARRIER_RESET_VALUE Active toolholder on RESET
20140 TRAFO_RESET_VALUE Transformation record on power-up (RESET / TP-
End)
20150 GCODE_RESET_VALUES Reset G groups
20152 GCODE_RESET_MODE RESET response of the G Groups
20184 TOCARR_BASE_FRAME_NUMBER Number of the basic frame for pickup of the table
offset
21015 INVOLUTE_RADIUS_DELTA NC start disable without reference point
22532 GEOAX_CHANGE_M_CODE M code for replacement of geometry axes
22534 TRAFO_CHANGE_M_CODE M code for transformation changeover
24000 FRAME_ADD_COMPONENTS Separate programming/modification of additively
programmable frame components
24002 CHBFRAME_RESET_MASK RESET response of channelspecific basic frames
24004 CHBFRAME_POWERON_MASK POWER ON response of channelspecific
basic frames
24006 CHSFRAME_RESET_MASK RESET response of channelspecific system frames
24007 CHSFRAME_RESET_CLEAR_MASK Clear system frames on RESET
24008 CHSFRAME_POWERON_MASK Delete system frames on POWER ON
24010 PFRAME_RESET_MODE RESET mode for programmable frame
24020 FRAME_SUPPRESS_MODE Positions for frame suppression
24030 FRAME_ACT_SET SZS coordinate system setting
24040 FRAME_ADAPT_MODE Adapting active frames
24050 FRAME_SAA_MODE Save and activate data management frames
24805 TRACYL_ROT_AX_FRAME_1 Rotary axis offset TRACYL 1
24855 TRACYL_ROT_AX_FRAME_2 Rotary axis offset TRACYL 2
24905 TRANSMIT_ROT_AX_FRAME_1 Rotary axis offset TRANSMIT1
24955 TRANSMIT_ROT_AX_FRAME_2 Rotary axis offset TRANSMIT2
28080 MM_NUM_USER_FRAMES Number of settable Frames (SRAM)
28081 MM_NUM_BASE_FRAMES Number of channelspecific base frames
28082 MM_SYSTEM_FRAME_FRAMES Configuration screen form for channel-specific system
frames
28560 MM_SEARCH_RUN_RESTORE_MODE Restore data after a simulation
