Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
159
Parameterization
Signal Type Value range Meaning
PIService ANY PI.TMFPBP Empty location search
Unit INT 1 ... max. TOA TOA
WVar1 INT MagazinNumber_From:
Magazine number of magazine from which
search must begin
WVar2 INT LocationNumber_From:
Location number of location in magazine
MagazineNumber_From at which search must
begin
WVar3 INT MagazineNumber_To:
Magazine number of magazine at which
search must end
WVar4 INT LocationNumber_To:
Location number of location in magazine
MagazineNumber_To at which search must
end
WVar5 INT MagazineNumber_Ref:
WVar6 INT LocationNumber_Ref:
WVar7 INT 0,
1 .. 7
Number of required half locations to left
WVar8 INT 0,
1 .. 7
Number of required half locations to right
WVar9 INT 0,
1 .. 7
Number of required half locations in upward
direction
WVar10 INT 0,
1 .. 7
Number of required half locations in downward
direction
WVar11 INT Number of required location type
WVar12 INT 0: default
1: forwards
2: backwards
3: Symmetrical
Specifies the required search direction
0: Empty location search strategy is set in
$TC_MAMP2
