Detailed description
2.2 Protection zones
Basic logic functions: Axis monitoring, protection zones (A3)
54 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB21, ... DBX278.0 to DBX279.1 (Channel-specific protection zone 1 - 10 violated)
Activate
The preactivated protection zones can be activated from the PLC user program:
DB21, ... DBX8.0 to DBX9.1 (Activate machine-related protection zone 1 - 10)
DB21, ... DBX10.0 to DBX11.1 (Activate channel-specific protection zone 1 - 10)
Deactivation
Protection zones activated from the part program cannot be deactivated by the PLC user
program.
Note
It follows from the rules listed above that protection zones that should be activated via the
PLC user program are intended specially for this. Preactivation in the part program is only
useful for these protection zones.
For protection zones that are known only in the part program and not in the PLC user
program, only activation in the part program makes sense.
Automatic activation after the control powers up
The configuration for automatic activation of a protection zone after the control powers up is
performed via the following system variable:
• Channel-specific protection zone:
$SC_PA_ACTIV_IMMED[ n ]
• Machine or NC-specific protection zone:
$SN_PA_ACTIV_IMMED[ n ]
With automatic activation, no relative offset of the protection zone is possible.
Block search with calculation
For block search with calculation, the last programmed activation state of a protection zone
is always taken into account.
Program test
In automatic modes, activated and preactivated protection zones are monitored even during
program control: PROGRAM TEST.
