Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
222 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
MD35010 GEAR_STEP_
CHANGE_ENABLE = 0
Function MD35010 GEAR_STEP_
CHANGE_ENABLE = 1
Function
Pos = 0 Oscillatio
n
Pos = 0
Pos = 1 Oscillatio
n
Pos = 1 Oscillation with gear stage
change M41
Pos = 2 Oscillatio
n
Pos = 2 Oscillation with gear stage
change M42
Pos = 3 Oscillatio
n
Pos = 3 Oscillation with gear stage
change M43
Pos = 4 Oscillatio
n
Pos = 4 Oscillation with gear stage
change M44
Pos = 5 Oscillatio
n
Pos = 5 Oscillation with gear stage
change M45
4. Traverse indexing axis:
The following signals are relevant:
Start: Initiation signal
Funct: "4" = Indexing axis
Note
With
Funct: "4" = Indexing axis
The modulo conversion can be compared with approaching the indexing position via
POS[AX] = CIC (value) in the part program.
Mode: Positioning mode 0, 1, 2, 3, 4
AxisNo: Number of machine axis
Pos: Indexing position
FRate: Positioning speed; if FRate = 0,
the value is taken from machine data POS_AX_VELO
(unit as set in machine data).
InPos: Is set to "1" when position is reached with "Exact stop fine".
Error : With positioning error = "1"
State : Error code
