Detailed description
2.1 Key PLC CPU data for 810D, 840D and 840Di
Basic logic functions: PLC basic program solution line (P3 sl)
12 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Version screen on HMI
In the version screen the currently used PLC and the related version of the PLC operating
system is displayed under PLC (e.g. PLC_317-2DP 20.70.31).
In the column after that the module code of the PLC module used can be read. The following
PLC module codes are currently in use:
Module code PLC module Suitable PLC operating
systems (corresponding
SIMATIC MLFB)
Operating system
SW version ID
201x PLC 317-2DP with
IBC32
6ES7 317-2AJ10-0AB0,
FW 2.1
20.70.31
MCI 2 (840Di)
211x
PLC 317-2DP with
IBC32
6ES7 317-2AJ10-0AB0,
FW 2.1
20.70.31
PLC basic program functions
840Di 840D sl
interfaces
MPI 1 1
Ethernet 2+1
Functions of basic program
Scope:
Axes/spindles
Channels
Mode groups
See catalog
6
6
31
10
10
Functions:
Status/control signals
M decoders (M00-99)
G group decoders
Aux. function distributors
Aux. function transfer, interrupt-driven
M decoding acc. to list
Move axes/spindles from PLC
Async. subprogram interface
Error/operating messages
Transfer MCP and HHU signals
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
Display control handheld unit + +
Read/write NCK variables and GUD + +
PI services + +
Tool management + +
Star/delta switchover + +
m:n
Safety integrated
Program diagnostics
+
+
+
+
+
