Detailed description
2.11 General conditions and NC-VAR_Selector
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
83
Testing and diagnostics (ONLINE)
Variable status/forcing (I/Os, flags, data block contents, etc.)
Status of individual blocks
Display of system states (ISTACK, BSTACK, system status list)
Display of system messages
PLC STOP/complete restart/overall reset triggering from the programming device
Compress PLC
Documentation
Printout of individual or all blocks
Allocation of symbolic names (also for variables in data blocks)
Input and output of comments within each block
Printout of test and diagnostics displays
Hardcopy function
Cross-reference list
Program overview
Assignment plan I/O/M/T/Z/D
Archiving of utility routines
Allocation of the output statuses of individual blocks
Comparison of blocks
Rewiring
STEP 5 -> STEP 7 converter
Option packages
Programming in S7–HIGRAPH, S7–GRAPH, SCL.
These packages can be ordered from the SIMATIC sales department.
Additional packages for configuration modules
(e.g., CP3425 -> NCM package)
Note
More information about possible functions can be found in SIMATIC catalogs and
STEP 7 documentation.
