Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
102 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Signal Type Type Range of values Remark
MCP1NotSend
MCP2NotSend
I BOOL 0: Send and receive operation
activated
1: Receive machine control panel
signals only
MCPSDB210 I BOOL false Available owing to compatibility
MCPCopyDB77 I BOOL false Available owing to compatibility
MCPBusType I BYTE b#16#33: Profibus
b#16#55: Ethernet
Mixed operation possible, see
MCP/HHU configuration
HHU I INT 0, 5 Handheld unit interface
0: No HHU
5: HHU on Ethernet
BHGIn I POINTER I0.0 to I124.0,
F0.0 to F252.0 or
DBn DBX0.0 to
DBXm.0
Start address
PLC receive data
from HHU
BHGOut I POINTER Q0.0 to Q124.0,
F0.0 to F252.0 or
DBn DBX0.0 to
DBXm.0
Start address
PLC transmit data
to HHU
BHGStatSend I POINTER Q0.0 to Q124.0,
F0.0 to F252.0 or
DBn DBX0.0 to
DBXm.0
Available owing to compatibility
BHGStatRec I POINTER Q0.0 to Q124.0,
F0.0 to F252.0 or
DBn DBX0.0 to
DBXm.0
Available owing to compatibility
BHGInLen I BYTE HHU default:
B#16#6 (6 Byte)
Available owing to compatibility
BHGOutLen I BYTE HHU default:
B#16#14 (20 Byte)
Available owing to compatibility
BHGTimeout I S5time Recommendation:
700 ms
Available owing to compatibility
BHGCycl I S5time Recommendation:
100 ms
Available owing to compatibility
BHGRecGDNo I INT HHU default: 2 Ethernet DIP switch
BHGRecGBZNo I INT HHU default: 2 Available owing to compatibility
BHGRecObjNo I INT HHU default: 1 Available owing to compatibility
BHGSendGDNo I INT HHU default: 2 Available owing to compatibility
BHGSendGBZNo I Int HHU default: 1 Available owing to compatibility
BHGSendObjNo I INT HHU default: 1 Available owing to compatibility
BHGMPI I BOOL false Available owing to compatibility
