2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
126 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Overview of PI services
The following section provides an overview of the PI services that can be started from the
PLC. The significance and application of the general FB 4 input variables (Unit, Addr ...,
WVar ...) depend on the individual PI service concerned.
PI service Function Available in 840D
ASUB Assign interrupt x
CANCEL Execute cancel x
CONFIG Reconfiguration of
tagged machine data
x
DIGION Digitizing on x
DIGIOF Digitizing off x
FINDBL Activate block search x
LOGIN Activate password x
LOGOUT Reset password x
NCRES Trigger NC-RESET x
SELECT Select program for processing for one channel x
SETUDT Sets the current user data to active x
SETUFR Activate user frame x
PI service Tool management function
CRCEDN Create new cutting edge x
CREACE Create cutting edge x
CREATO Generate tool x
DELECE Delete a cutting edge x
DELETO Delete tool x
MMCSEM Semaphores for various PI services x
TMCRTO Create tool x
TMFDPL Empty location search for loading x
TMFPBP Empty location search x
TMGETT T-number for the specified
tool identifier with duplo number
x
TMMVTL Prepare magazine location for loading, unload tool x
TMPOSM Position magazine location or tool x
TMPCIT Set increment value for workpiece counter x
TMRASS Reset active status x
TRESMO Reset monitoring values x
TSEARC Complex search using search screen forms x
x: PI service is available
