Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
223
Channel signals
Source:
MCP - Keys
Destination:
Interface DB (parameter ChanNo)
NC start DB21, ... DBX7.1
NC stop DB21, ... DBX7.3
RESET DB21, ... DBX7.7
Single BLock DB21, ... DBX0.4
Feedrate, spindle signals
Source:
MCP - Keys
Destination:
FC output parameters
Feed stop
Feed enable
Parameter: "FeedHold" latched, LEDs are driven
Spindle stop
Spindle enable
Parameter: "SpindleHold" latched, LEDs are
driven
Checkback signals from user interface for controlling displays
Operating modes and machine functions
Destination:
MCP - LED
Source:
Interface DB (parameter BAGNo)
AUTOMATIC DB11, ... DBX6.0
MDI DB11, ... DBX6.1
JOG DB11, ... DBX6.2
REPOS DB11, ... DBX7.1
REF DB11, ... DBX7.2
TEACH IN DB11, ... DBX7.0
Destination:
MCP - LED
Source:
Interface DB (parameter BAGNo)
INC 1 ... 10 000, INC Var. DB11, ... DBB8, Bit 0 to 5
