Siemens MCP 398C Function Manual

Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
246 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The corresponding interface bits are
deleted for axes that are not selected.
Source:
MCP - Key
Destination:
Interface DB (parameter ChanNo)
Direction key + DB21, ... DBX12.7
Direction key - DB21, ... DBX12.6
Rapid traverse override DB21, ... DBX12.5
Direction key + DB21, ... DBX16.7
Direction key - DB21, ... DBX16.6
Rapid traverse override DB21, ... DBX16.5
Direction key + DB21, ... DBX20.7
Direction key - DB21, ... DBX20.6
Rapid traverse override DB21, ... DBX20.5
Source:
MCP - Key
Destination:
Interface DB (6 assigned axis DBs)
Direction key + DB31, ... DBX4.7
Direction key - DB31, ... DBX4.6
Rapid traverse override DB31, ... DBX4.5
Override
Source:
MCP - Setting
Destination:
Interface DB (parameter ChanNo)
Feedrate override DB21, ... DBB4
Source:
MCP - Setting
Destination:
Interface DB (6 assigned axis DBs)
Feedrate override DB31, ... DBB0 (selected axis number)
The feedrate override of the 1st MCP is applied to 6
axes.
Channel signals
Source:
MCP - Keys
Destination:
Interface DB (parameter ChanNo)
NC start DB21, ... DBX7.1
NC stop DB21, ... DBX7.3
RESET DB21, ... DBX7.7
Single BLock DB21, ... DBX0.4
